Drilling machine

DRILLING MACHINE TBH - Idel for the lab, workshop and delicate operations

• Table and arm of the table drilling machine offered here are made of die-cast aluminium
• A refined, rust-proof and statically very solid material
• Fittings and feeds are machined on our highly modern CNC-controlled machines (milled, line-bored, lathed, etc.)
• Powerful, long-lasting direct current motor
• Spindle drive via triple belt pulley with the advantage of roughly 6 times the torque in the lower rotational speed range
• Practical drill depth indicator with adjustable limit stop
• Drill spindle with precision bearing
• Spindle head with 1/2" thread for the corresponding RÖHM gear tooth chuck (industrial quality)
• Spindle with additional fit for steel collets NO 28 200
• Ideal for jig boring with the compound table KT 150 ( order-no. 3594K )

• technical data

  • power : 220 - 240 Volt
  • spindle rotational speeds : 1.080; 2.400 and 4.500 rpm
  • sliding sleeve stroke : 63 mm
  • height adjustment via crank : 70 mm
  • throat : 140 mm
  • usable table surface : 200 x 200 mm
  • column : 45 x 500 mm
  • tool holder up to : 10 mm
  • drilling performance in steel : 10 mm
  • weight : approx. 10 kg
