CARAT SCALE - 200 ct/0.001ct Cal. Ext.
Precision Scale Ohaus 200ct/40gr-0.001ct/0.0001gr - Weighing pan: Ø 90mm - you need an external Calibration weight
Applications
Basic Weighing, Parts Counting, Percent Weighing, Density Determination
Display
Backlit Liquid Crystal Display (LCD)
Operation
AC adapter (included)
Communication
RS232 interface and Mini-Din port (for connecting auxiliary display)
SPECIFICATIONS
Maximum Capacity: 40 g/200 ct
Readability: 0.0001 g; 0.001 ct
Pan Size: 3.5 in (90 mm)
Communication: RS232
Dimensions: 321 mm x 274 mm x 209 mm (LxHxW)
Display: LCD with backlight
Internal Calibration: Not applicable
In-Use Cover Included
Legal for Trade: Not applicable
Linearity: ± 0.0002 g
Net Weight: 10 lb (4.5 kg)
Pan Construction Stainless Steel
Power AC Adapter (Included)
Repeatability, typical: 0.0001 g
Stabilization Time: 3 s
Tare Range To capacity by subtraction
Units of Measurement: Milligram; Ounce Troy; Pennyweight; Taiwan Tael; Gram; Grain; Carat; Ounce; Custom
Working Environment: operability guaranteed between 41°F and 104°F; 50°F – 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C; 10°C – 30°C, 80%RH, non-condensing)
